Enersol S16 Falling Drop Liquid Leakage Tester for ISO594



ENERSOL S16 Falling Drop LIQUID LEAKAGE TEST MACHINE for ISO 594

NOTE:
ISO 594 has been rescinded and replaced by ISO 80369-7. Because of the change from ISO 594 into ISO 80369-7; all tests per ISO 594/1 and ISO 594-2 should now be switched to tests per ISO 80369-7 (ISO 80369-20).

NOTE:
Enersol Model S16 Falling Drop Liquid Leak Test Device is no longer available for purchase. Replacement was S16A Falling Drop Liquid Leak Test Device and has been repalced by S16B Falling Drop Liquid Leak Test Device.The physical changes in the new models make it unecconomical to upgrade them.

NOTE:
Enersol Model S16B Positive Pressure Liquid Leakage Tester has been designed specifically for ISO 80369 tests as listed in ISO 80369-20. Enersol Model S16B Positive Pressure Liquid Leakage Tester is backward compatible to ISO 594.

Enersol S16 Falling Drop Liquid Leak Tester



Uses for the Enersol S16 Positive Pressure Liquid Leakage Tester
Below is a list of tests which are best accomplished by using the Liquid Leakage Test Machine.

ISO 594/1 Liquid Leakage Test as defined in paragraph 4.2*
To conduct the Liquid Leakage Test found in ISO 594/1 paragraph 4.2 the following Enersol products are required:
S11 - Male Reference Fitting ISO594/1 Figure 5 and/or
S12 - Female Reference Fitting ISO594/1 Figure 4
S15 - Force/Torque Fitting Assembly Machine
S16 - Liquid Leakage Test Machine
*NOTE: Per ISO 80369-20; Annex A; Paragraph A.2; Page 4; Annex C Falling drop positive-pressure liquid leakage test method:
This liquid leakage test method is performed in the same manner as in the ISO 594- series.

ISO 594/2 Liquid Leakage Test as defined in paragraph 4.2.1*
To conduct the Liquid Leakage Test found in ISO 594/2 paragraph 4.2.1 the following Enersol products are required:
S07 - Male Reference Fitting ISO594/2 Figure 5 and/or
S09 - Female Reference Fitting ISO594/2 Figure 7
S15 - Force/Torque Fitting Assembly Machine
S16 - Liquid Leakage Test Machine
*NOTE: Per ISO 80369-20; Annex A; Paragraph A.2; Page 4; Annex C Falling drop positive-pressure liquid leakage test method:
This liquid leakage test method is performed in the same manner as in the ISO 594- series.

Disclaimer
This data is provided for general information only. The intention is to provide accurate information; regardless; errors may exist in the supplied information. If accuracy is critical, base your final decisions on the data provided in the root documents which are usually copyrighted documents. To purchase a copy of an engineering document visit an Authorized Reseller.
